The XM 1000 monochromatic X-ray source product | © Scienta Omicron
XM1000 monochromatic X-ray source.
Example of a typical XM 1000 system  | © Scienta Omicron
XM1000 on a typical system.


Monochromatic X-ray Source with Excellent Energy Resolution


  • High x-ray flux for fast sample analysis
  • Excellent energy resolution
  • Fully software integrated
  • Robust mechanical alignment

The XM1000 monochromated X-ray source provides optimum photon flux and excellent energy resolution. In addition, low background and the absence of satellites are key advantages of the XM1000 over non-monochromated X-ray sources. Narrow core level peaks and low background simplifies identification of the surface chemistry by XPS and other X-ray spectroscopy applications.

The XM1000 offers excellent performance with high photon brightness and a line width below 0.25 eV. Ease-of-use is guaranteed by a fully software controlled digital power supply combined with a simple alignment procedure of the complete monochromator. This ensures optimum performance of the XM1000 every day.

Contact Us Email:


Anode material

Al (Al Kα: 1486.6 eV)

Maximum anode voltage

15 kV

Rowland circle diameter

500 mm

Minimum spot size

Approx. 1 mm

Photon linewidth

< 250 meV

Maximum continuous power

300 W

Bake-out temperature

130 °C

Flange to sample distance

203 mm

Mounting port

DN63CF (4.5" O.D.)

For full specifications and more information about product options, please do not hesitate to contact your local sales representative. Find the contact details here: Contact Us
